Solar Panel
half cell solar panels 500w 550w 525w black frame 182 cell roof system
Solar Panel Power:540W 545W 550W 555W 560W Use Life:30Years Efficiency:22% Warranty:15Years For Materials Warranty,30Years For Efficiency Warranty.- Solar Panel Power: 540W 545W 550W 555W 560W Use Life
- Product Details
- Download
Features
- Nominal 36V DC for standard output.
- Efficiency: 20.85%( Use Solar cell with 23% Efficiency).
- Outstanding low-light performance.
- High transmission tempered glass.
- Rugged design to withstands high wind pressure and snow load, easy installation.
- Aesthetic appearance.
- Design to meet unique demand of customer.
- 25 year module output warranty.
|
|
|
|
|
|
Electrical Characteristics
|
Maximum power at STC（Pmax） |
540W |
545W |
550W |
555W |
560W |
|
Optimum operating voltage（Vmp） |
39.42V |
39.450V |
39.49V |
39.502V |
39.520V |
|
Optimum operating current（Imp） |
13.774A |
13.815A |
13.942A |
14.05A |
14.17A |
|
Open-circuit voltage（Voc） |
48.08V |
48.08V |
48.077A |
48.081V |
48.09V |
|
Short-circuit current（Isc） |
14.543A |
14.657A |
14.672A |
14.690A |
14.72A |
|
Short-circuit current temperature coefficient （0.065±0.015）%/℃ |
|||||
|
Open-circuit voltage temperature coefficient -（80±10）mV/℃ |
|||||
|
Peak power temperature coefficient -（0.5±0.05）%/℃ |
|||||
|
NOCT (Air 20℃; Sun 0.8kW/m wind 1m/s) 47±2℃ |
|||||
|
Operating temperature -40℃ to 85℃ |
|||||
|
Maximum system voltage 1000V DC |
|||||
|
Power tolerance ±3% |
|||||
\
