Off Grid Solar Power System
Solar Energy Storage System 10KW/30KWH
- 10KW solar inverter+30KWH lithium battery all in one:
- Product Details
- Download
Solar Energy Storage System 10KW/30KWH
|
Product |
MS-10KW/30KWH |
|
Operating Temperature |
-10~50℃ |
|
Protection Rating |
IP32 |
|
AC Output |
|
|
Voltage |
230V |
|
Frequency |
50/60HZ |
|
Current |
43.5A |
|
Power |
10000W |
|
PV Input |
|
|
Maximum Power |
11000KW |
|
Maximum Current |
200A |
|
Allowed Input Voltage |
60-500VDC |
|
Optimal Input Voltage |
300-400VDC |
|
AC Input |
|
|
Voltage |
230V |
|
Frequency |
50/60HZ |
|
Current |
71.6A |
|
Battery |
|
|
Operating Voltage (DC) |
43.2-58.4V |
|
Rated Voltage (DC) |
51.2V |
|
Energy |
30.72kwh |
|
Capacity |
600AH |
|
Dimensions |
564*484* 1280 |
|
Weight |
≈315KG |
|
|
| Q:What include in this Solar Energy Storage System 10KW/30KWH? |
| A:It include 10KW solar inverter,30KWH lithium battery |
| Q:What are the advantage for this solar energy storage system? |
|
A:It is convenience for the solar system installation,the solar inverter and battery have been connected and installed. |
| Q:How long is the lead time of orders? |
| A:Goods can be ready for shipment within 7-15 working days upon payment.If we have stock material.It only take 1-2 days to send goods. |
| Q:What is the warranty of products? |
| A:Suggest buy solar system from our factory, solar panel have 25 years warranty ,other parts all have 2 years warranty;During the warranty, will ship the free parts for service ,we promise our quality. |
| Q:Can I install it myself? |
| A:We provide installation drawing and user manual for you,guide the installation.If necessary,we can send our engineer come to country,and guide the installation. |
| Q:How to calculate the freight? |
| A:We will calculate according to the specific location and transportation method, you can discuss it in detail with us. |
| Q:Can we get support if we have our own market position? |
| A:Please inform us your details market demand we will discuss and propose helpful suggestion for you to find the best solution for you. |
