3HP Solar Water Pump For Farm Manufacturer
3HP Solar Water Pump
3HP Solar Water Pump
3HP Solar Water Pump

3HP Solar Water Pump For Farm Manufacturer

Solar power system for 2.2KW 3HP submersible water pump, 50HZ,220V single phase

Product Specification:
  • Product name: 3HP Solar Water Pump
  • Solar panel power: 3500W
  • Water pump inverter: 4KW
  • Allow to connect water pump power: 2.2KW
  • Voltage: 220V50HZ single phase
Inquiry Now
  1. Product Details
  2. Download

3HP Solar Water Pump For Farm Manufacturer 3HP Solar Water Pump For Farm Manufacturer 3HP Solar Water Pump For Farm Manufacturer

          This solar system supply power to 2.2KW 3HP 220V50HZ single phase water pump,it is not include the water pump,water pump will design base on your requirement.

3HP Solar Water Pump For Farm Manufacturer 10pcs 350W poly solar panel
Vmp:38.7V  Voc:47.2V  Imp :9.59A
Size : 1956*992*40mm
25 years life time  (CE TUV)
Coated steel Glass:3.2mm Tem pered
Terminal block:IP65 with MC4 connector
Efficiency performance :25 years 80 % 20 year 85% 10 years 90%
3HP Solar Water Pump For Farm Manufacturer 1set Slope Roof or Flat roof or Ground (option)
including complete fittings
wind load:55m/s,snow load:1.5kn/m2
structure: Anodized Aluminum +stainless steel, Angle adjustable
(other type of rack can be customized as per client's requirement )
3HP Solar Water Pump For Farm Manufacturer 4KW solar water pump inverter
Solar input votage:310V
MPPT controller: 450V-700V
MPPT effeiceny: 99.99%
Thunder protection,water full protection
Output:220V single phase
3HP Solar Water Pump For Farm Manufacturer

1)From solar panel to inverter: 4mm2 PV cable:100M
2)From inverter to pump: 3*2.5mm2 AC cable:100M



      If i want to  buy complete set solar water pump for farm,how can i know which solar water pump system is suitable for me?

Pls provide these information to us then we can provide the professional guide to you:
What is the fluid ?
Clean water(temperature), dirty water(temperature), particles,or slurry ?
Daily Water Supply: ______m3
Static haed(vertical height from the pump to the highest point of delivery):________   m
Motor Cable length( the cable between controller and pump) :__________m
Pipeline length(Entire pipeline from the pump outlet to the point of delivery) :____________m
Slope or horizonal between borehole and tank _____________

3HP Solar Water Pump For Farm Manufacturer

3HP Solar Water Pump For Farm Manufacturer Solar Pump ManufacturersSolar Pump Manufacturers  Solar Pump ManufacturersSolar Pump ManufacturersSolar Pump Manufacturers

    Foshan Mars Solar Technology Co.,Ltd have more than 10 years factory experience for solar power system,solar water pump for farm products,solar street light products,inverter products,solar appliance products.More than 3000 successfully case have installed in 130+ countries.Germany technology,China price,Global service. Sincerely welcome everyone join us and develop solar business.

3HP Solar Water Pump For Farm Manufacturer Solar Water Pump PriceSolar Water Pump Price Solar Water Pump Price Solar Water Pump PriceSolar Water Pump Price

1.Q: Are you a manufacturer or trading company?
   We are a manufacturer that specialized in 3HP solar water pump 12 years. our products have abtained the CE  certificate.


2.Q: How can I get some samples?
  we accept the sample order, but need to be paid.


3.Q: What's your delivery time?
  1.The samples can be sent to you within 3-5days.
   2.The batch order can be shipped to you within 5-15days after order confirmation
